Electric Floor Crane
Introducing our premium selection of electric floor cranes, crafted to cater to the diverse lifting requirements of modern industries. Our range includes portable electric cranes for easy maneuverability, heavy-duty models for robust lifting tasks, and compact electric floor cranes for space-constrained environments. Each crane is engineered with precision, focusing on safety, reliability, and operational efficiency. Whether you need an electric lifting crane for a specific project or a mobile electric crane for regular use, we provide top-quality solutions along with comprehensive information on electric crane safety and operation. Our rental and purchasing options ensure that you have access to the best lifting equipment tailored to your needs.
Product Description
Our Electric Floor Crane is designed for efficient material handling, with an electrically extendable, retractable, and rotatable arm, suitable for lifting and moving materials up to a maximum capacity of 1 ton. The arm's lifting mechanism allows for precise vertical movement, with the hook reaching a minimum height of 600mm above the ground, making it ideal for engaging with materials positioned at or above this height.
The crane is equipped with outriggers that have an inner width of 680mm, perfectly accommodating materials narrower than 680mm. This feature also enables the straddles to easily enter pallets for efficient lifting. Designed for pedestrian operation, this electric Floor Crane is highly effective in plant areas, warehouses, and workshops with flat flooring. Its user-friendly design and operational efficiency make it an excellent choice for various material handling needs in these environments.
Product Information
Technical Data
Electric Floor Crane | SDC-A-0530 | SDC-A-1025 | SDC-A-1030 |
Capacity (kg) | 500 | 1000 | 1000 |
Lifting Height (mm) | 3000 | 2500 | 3000 |
Battery (V/Ah) | 24/80 | 24/120 | 24/120 |
Charger (V/A) | 24/15 | 24/15 | 24/15 |
Lifting Motor (Kw) | 2.5 | 2.5 | 2.5 |
Driving Motor (Kw) | 0.75 | 0.75 | 0.75 |
Rotation (°) | ±90° | ±90° | ±90° |
Outriggers Length (mm) | 950 | 950 | 950 |
Outriggers Inner Width (mm) | 680 | 680 | 680 |
Straddles Overall Width (mm) | 990 | 990 | 990 |
Outriggers Ground Clearance (mm) | 200 | 200 | 200 |
Min. Arm Extending Distance from Outriggers (mm) | 420 | 400 | 350 |
Weight (Kg) | 1460 | 1590 | 1680 |
Overall size(mm) L*W*H | 2670*990*1800 | 2900*990*1600 | 2900*990*1800 |
Turning Aisle (mm) | 2800 | 3100 | 3100 |
Passing Aisle (mm) | 1100 | 1100 | 1100 |
Driving wheel (mm) | 1*¢200*70 | ||
Auxiliary Wheels (mm) | 2*¢150*50 | ||
Front Wheels (mm) | 2*¢150*75 | ||
Climbing slope (％) | 3/5 | ||
Travel Speed (km/h) | 4/6 Loaded/Unloaded | ||
Lifting Speed (mm/s) | 45/50 Loaded/Unloaded | ||
Falling Speed (mm/s) | 45/40 Loaded/Unloaded | ||
Service Brake | Electromagnetic braking | ||
Note：All products are our standard products, design and specification are subject to change without prior notice.
